GR-150 Customization Low Density Graphite Anode Rod Extruded Graphite

Model NO. : GR-150

Grade : Industrial Grade

Forming Way : Extruded Graphite

Crystal Morphology : Flake Graphite

Composition : 100% Carbon

Transport Package : by Ply-Wood

Specification : 20-75mm

Trademark : DC

Origin : Beijing, China

HS Code : 2701121000

Supply Ability : 150PCS Per Day

Customization : Available

Density : 1.6

Type : Graphite Rod

Place of Origin : China

Delivery Time : Peak Season Lead Time: 6-12 months, Off Season Lead Time: 1-3 months

Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram

MOQ : 1 Piece

Contact Now

China manufacturer low density graphite anode rod:
Graphite rods are often used for following:
1. Refractory material:
Widely used in the metallurgical industry.
2. Conducting material:
In the electronics industry, widely used for graphite electrode, brush,, etc
3. Wear-resisting material and lubricant:
Use graphite as wear-resisting and lubrication materials, can be 100m/s speed sliding in - 200 ~ 2000 °C temperature range, no or less lubricanting oil.
4. Sealing material:
It can be as sealing ring in the equipment, such as centrifugal pump, hydraulic turbine , etc.
5. Anticorrosion material:
Widely used in petroleum, chemical, hydrometallurgy departments.
6. Protection materials
Insulation, high temperature resistant, radiation
Specifications:

Diameter	length (mm)	around weight kgs
Φ20	1700	1
Φ25	1700	1.5
	1900	1.68
	2200	1.95
	2250	1.98
Φ30	1700	2
	1900	2.24
	2200	2.59
Φ35w	1700	2.85
	1900	3.2
	2100	3.52
	2200	3.68
Φ40	1700	3.5
	1900	4
	2100	4.32
	2200	4.63
	2400	5.05
	2270	4.7
Φ45	2250	5.21
Φ50	1700	5.5
	1920	6.3
	2100	6.8
	2200	7.12
	2500	8
Φ60	1400	6.5
	1700	7.9
	1300	6.04
Φ63	2000	8.7
Φ70	2100	5.68
	2250	5.5
	2500	6.3
Φ72	2250	15.7
Φ72	2470	17
Φ75	2250	16.4

Technical date sheet:

Specifications	Unit	Value
Bulk Density	g/cm3	1.65-1.80
Compressive Strength *	MPa	20-55
Bending Strength *	MPa	10-30
Elastic Modulus *	GPa	9-21
Specific Resistance *	μ Ω·m	5.0-15.0
Ash	%	0.05-0.5
